Shadow Varsity 88 Embroidery Design: Outline Jersey Number Machine Embroidery File

The Shadow Varsity 88 embroidery design is a large-format varsity jersey number pair rendered as pure outline construction in a single dark charcoal thread with no interior fill. Both numerals are identical "8" characters, each with a heavily chamfered rectangular outer silhouette, two fully enclosed rectangular counter spaces stacked vertically, and a mid-waist junction where the upper and lower counter frames meet at the center of the numeral. The dual-column satin outline construction traces the outer perimeter, the mid-waist junction band, and the inner edges of both counters in each "8," leaving all fabric exposed within the counter openings and the numeral body. The design is single-color charcoal with no thread changes. Total stitch count is 14,329 stitches at 8.70 x 7.18 inches.

What makes this design technically distinct from all other Shadow Varsity designs in this collection is the repeated duplicate numeral: both characters are identical "8" forms, which means any digitizing inconsistency between the left and right instances is immediately visible as a symmetry discrepancy when the two are compared side by side. More importantly, the "8" is the only numeral in the Shadow Varsity series with two fully enclosed interior counters, meaning the inner column path must form two complete closed loops within a single character in addition to tracing the outer perimeter. No other numeral in the series requires the inner column to close on itself twice within the same character, making the total closed-path count per numeral higher in this design than in any other in the collection.

Design Details

Both "8" numerals share identical construction and are presented at matched scale side by side. Each "8" has a broad rectangular outer silhouette with chamfer cuts at all eight outer corners, producing an octagonal-style perimeter consistent with the chamfer language of the Shadow Varsity series. The outer column traces this full chamfered perimeter in a single continuous path. Inside the outer perimeter, the numeral stroke is divided at the mid-waist, a horizontal band crossing the center of the "8" that separates the upper counter from the lower counter. This mid-waist band is stitched as part of the continuous outer column path, with the column widening slightly at the waist junction to maintain visual weight consistency through the transition. Inside the upper half of each "8," a fully enclosed rectangular counter is defined by the inner column running a complete closed loop around the upper counter opening. Inside the lower half, a second closed inner column loop defines the lower counter. Both counter loops are connected to the main column path at the mid-waist junction, where the inner column transitions between the two closed loops as part of a single continuous stitch sequence. The result is a design where each "8" requires the satin column to complete two enclosed inner loops and one full outer perimeter pass, more closed-path stitching per character than any other numeral in the Shadow Varsity series. White fabric is fully exposed within both counters and throughout the numeral body of each "8."

Size Guide

Formats Included

This design includes 26 machine embroidery formats compatible with all major brands and software: PES, PEC (Brother, Baby Lock, Bernina) | DST, DSB (Tajima) | JEF, SEW (Janome, Elna) | VP3, VIP, SHV, HUS (Husqvarna Viking) | PCS, PCQ, PCD (Pfaff) | XXX (Singer) | ART (Bernina software) | 000 (Singer/generic) | 100 (Toyota) | CND (Melco/Conde) | CSD (Singer/POEM) | DGT (Barudan) | DSZ (Tajima older) | EMD (Elna) | EXP (Melco/Bernina) | INF (design info).

Digitizing Quality

The primary technical challenge in this design is routing the inner column through two complete enclosed counter loops per numeral in a single continuous stitch path without a jump thread between the upper and lower counter. The transition between the two closed inner loops occurs at the mid-waist junction, where the inner column must exit the upper counter loop, traverse the waist band, and enter the lower counter loop in a continuous sequence. If this transition requires a jump, a travel thread crosses the visible white counter area and ruins the clean open-fabric appearance the design depends on. The transition path was routed along the inner edge of the waist band itself, using the waist band satin as a bridge between the two counter loops so the thread travels concealed beneath the waist fill rather than across open fabric.

The second challenge was the inter-numeral symmetry between the two identical "8" characters. Because both numerals are the same form, any difference in counter size, chamfer angle, waist band width, or column weight between the left and right instance is immediately readable as an error. The right "8" was constructed as a direct copy of the left "8" path set rather than as an independently digitized character, with position offset applied uniformly to all paths so that every measurement relationship within the right instance is geometrically identical to the left instance at every point.

The third challenge was the eight chamfered corners of each "8" outer perimeter. With eight chamfers per numeral and two numerals in the file, this design contains sixteen mitered column transitions, more than any other design in the Shadow Varsity series. Each miter must be individually mapped to its specific corner angle, and because the chamfer cuts on an "8" occur at varying positions around the perimeter, including at the waist junction flanks, the corner angles are not all identical. Each of the sixteen miters was verified against its specific geometric corner angle rather than applied from a shared template, ensuring consistent miter quality around both full perimeters.

License

This file is licensed for use on finished physical goods only. You may stitch and sell embroidered items made from this design. The digital files themselves may not be resold, redistributed, shared, or included in any digital product bundle.

Instant Download

Your files are available immediately after purchase. This listing includes 1 size in all 26 embroidery formats, zipped and ready to transfer directly to your machine or software. No waiting, no requests needed. Add to cart, download, and stitch.
